QF Double Branch – PLEASE CALL FOR A PRICE

£0.00 +VAT

Category:

Description

QF DOUBLE BRANCH – PLEASE CALL FOR A PRICE

When ordering QF Double Branches, specify Ø1, Ø2, Ø3, Ø4.

double_branch_diagram

L1 = ( Ø2 x 2 ) + 236
L2 = ( Ø2 / 2 ) + 58
Ø3 must be smaller than or equal to Ø1
Ø2 must be smaller than or equal to Ø3
Ø4 must be smaller than or equal to Ø3

double branch



Additional information

Diameter

100, 125, 140, 150, 160, 180, 200, 224, 250, 300, 315, 350, 400, 450, 500, 560, 630, 710, 080
